Wiring table Lower windchest

Note number wire color PIC board PC board output number Weidmuller number remarks
34 - 1 (K1) 1 2 - 3p not connected - 3pole connector
34.5 - 2 (Q1) 1 2 - 3p not connected - 3pole connector
35 black 1 2 3 -3p blue lites, normal note side, 3 pole Weidmuller connector (+24V)
35.5 blue 2 2 3 - 3p blue lites, quartertone note side, 3 pole Weidmuller connector (+24V)
36 black 1 3 1 - 16 pole normal note, 16 pole Weidmuller connector - K side
36.5 black 2 3 1 quartertone note - Q side
37 brown 1 4 2 K side
37.5 brown 2 4 2 Q side
38 red 1 5 4 K side
38.5 red 2 5 4 Q side
39 orange 1 6 5 K side
39.5 orange 2 6 5 Q side
40 yellow 1 7 6 K side
40.5 yellow 2 7 6 Q side
41 green 1 8 7 K side
41.5 green 2 8 7 Q side
42 blue 1 9 9 K side
42.5 blue 2 9 9 Q side
43 purple 1 10 10 K side
43.5 purple 2 10 10 Q side
44 grey 1 11 11 K side
44.5 grey 2 11 11 Q side
45 white 1 12 12 K side
45.5 white 2 12 12 Q side
46 black 1 13 14 K side
46.5 black 2 13 14 Q side
47 brown 1 14 15-16pole frontal pipe on low windchest, normal note side (K side)
47.5 brown 2 14 15-16pole frontal pipe on low windchest, quartertone note side (Q side)

note: 16-pole Weidmuller pins 3, 8, 13, 16 on both boards are connected to the common positive power supply. Two 1.5mm2 red colored wires from the windchest are connected to the common positive voltage for the solenoids. A 0.75mm2 red wire is the common positive (+24V) voltage for the ligths,



Wiring table Upper windchest:

Note number wire color PIC board PC board output Weidmuller connector pin remarks
48 black 3 (K2) 1 2/16 lowest pipe on upper windchest (K side)
48.5 black 4 (Q2) 14 15/16 lowest quartertone pipe op upper windchest (K-side)
49 brown 3 2 3/16 second normal pipe on upper windchest (Q side)
49,5 brown 4 13 14/16 quartertone pipe on middle row (Q side)
50 red 3 3 4/16 K side
50.5 red 4 12 12/16 K side
51 orange 3 4 5/16 Q side
51.5 orange 4 11 11/16 Q side
52 yellow 3 5 7/16 K side
52.5 yellow 4 10 10/16 K side
53 green 3 6 8/16 Q side
53.5 green 4 9 9/16 Q side
54 blue 3 7 9/16 K side
54.5 blue 4 8 7/16 K side
55 purple 3 8 10/16 Q side
55.5 purple 4 7 6/16 Q side
56 grey 3 9 12/16 K side
56.5 grey 4 6 5/16 K side
57 white 3 10 13/16 Q side
57.5 white 4 5 4/16 Q side
58 black 3 11 14/16 K side
58.5 black 4 4 2/16 K side
59 brown 3 12 15/16 Q side
59.5 brown 4 3 1/16 Q side
60 red 3 13 1/3 K side
60.5 red 4 2 13 K side
61 orange 3 14 2/3 Q side
61.5 orange 4 1 15/16 Q side
62 yellow 5 (K3) 1 2/16 K side
62.5 yellow 6 (Q3) 14 14/16 K side
63 green 5 2 3/16 Q side
63.5 green 6 13 12/16 Q side
64 blue 5 3 4/16 K side
64.5 blue 6 12 11/16 K side
65 purple 5 4 5/16 Q side
65.5 purple 6 11 10/16 Q side
66 grey 5 5 7/16 K side
66..5 grey 6 10 9/16 K side
67 white 5 6 8/16 Q side
67.5 white 6 9 7/16 Q side
68 black 5 7 9/16 K side
68.5 black 6 8 6/16 K side
69 brown 5 8 10/16 Q side
69.5 brown 6 7 5/16 Q side
70 red 5 9 12/16 K side
70.5 red 6 6 4/16 K side
71 orange 5 10 13/16 Q side
71.5 orange 6 5 2/16 Q side
72 yellow 5 11 14/16 K side
72.5 yellow 6 4 1/16 K side
73 green 5 12 15/16 Q side
73.5 green 6 3 3/3 Q side
74 blue 5 13 1/3 K side
74.5 blue 6 2 2/3 K side
75 purple 5 14 2/3 Q side
75.5 purple 6 1 15/16 Q side
76 grey 7 (K4) 1 2/16 K side
76.5 grey 8 (Q4) 14 14/16 K side
77 white 7 2 3/16 Q side
77.5 white 8 13 12/16 Q side
78 black 7 3 4/16 K side
78.5 black 8 12 11/16 K side
79 brown 7 4 5/16 Q side
79.5 brown 8 11 10/16 Q side
80 red 7 5 7/16 K side
80.5 red 8 10 9/16 K/Q side central middle row
81 orange 7 6 8/16 Q side
81.5 orange 8 9 7/16 K/Q side central middle row
82 yellow 7 7 9/16 K side
82.5 yellow 8 8 6/16 K side innercircle
83 green 7 8 10/16 Q side
83.5 green 8 7 5/16 Q side innerrow
84 blue 7 9 12/16 K side
84.5 blue 8 6 4/16 K side innercircle
85 purple 7 10 13/16 Q side outerrow
85.5 purple 8 5 2/16 Q side innerrow
86 grey 7 11 14/16 K side
86.5 grey 8 4 1/16 K side innercircle
87 white 7 12 15/16 Q side outerrow
87.5 white 8 3 3/3 Q side innerrow
88 black 7 13 1/3 K side, back circle start
88.5 black 8 2 2/3 Q side circle
89 brown 7 14 2/3 K side innercircle
89.5 brown 8 1 15/16 Q side innerrow
90 red 9 (K5) 1 2/16 K side innercircle
90.5 red 10 (Q5) 14 14/16 Q side innercircle
91 orange 9 2 3/16 K side innercircle
91.5 orange 10 13 12/16 Q side innercircle
92 yellow 9 3 4/16 K side innercircle
92..5 yellow 10 12 11/16 Q side innercircle
93 green 9 4 5/16 K side innercircle
93.5 green 10 11 10/16 Q side innercircle
94 blue 9 5 7/16 K side innercircle
94.5 blue 10 10 9/16 Q side innercircle
95 purple 9 6 8/16 K side innercircle
95.5 purple 10 9 7/16 Q side innercircle
96 grey 9 7 9/16 K side, circle
96.5 grey 10 8 6/16 Q side circle
97 white 9 8 10/16 K side, circle
97.5 white 10 7 5/16 Q side circle
98 black 9 9 12/16 K side, circle
98.5 black 10 6 4/16 Q side circle
99 brown 9 10 13/16 K side, circle
99.5 brown 10 5 2/16 Q side circle
100 red 9 11 14/16 K side, circle
100.5 red 10 4 1/16 Q side circle
101 orange 9 12 15/16 K side, circle
101.5 orange 10 3 3/3 Q side circle
102 yellow 9 13 1/3 K side, circle
102.5 yellow 10 2 2/3 Q side circle
103 green 9 14 2/3 K side circle
103.5 green 10 1 15/16 Q side circle
104 blue 11 (K6) 1 2/16 K side circle
104.5 blue 12 (Q6) 14 14/16 Q side circle
105 purple 11 2 3/16 K side circle
105.5 purple 12 13 12/16 Q side circle
106 grey 11 3 4/16 K side circle
106.5 grey 12 12 11/16 Q side circle
107 white 11 4 5/16 K side circle
107.5 white 12 11 10/16 Q side circle
108 black 11 5 7/16 highest note in Qt (central pipe on extreme end of outer circle)
108.5 - 12 10 9/16 not connected
109 - 11 6 8/16 not connected
109.5 - 12 9 7/16 not connected
110 green/yellow 11 7 9/16 blue lite center back (+24V)
110.5 - 12 8 6/16 not connected
111 white/red 11 8 10/16 blue lite K side (+24V)
111.5 white/black 12 7 5/16 blue lite Q side (+24V)
112 - 11 9 12/16 not connected
112..5 - 12 6 4/16 not connected
113 - 11 10 13/16 not connected
113.5 - 12 5 2/16 not connected
114 - 11 11 14/16 not connected
114.5 - 12 4 1/16 not connected
115 - 11 12 15/16 not connected
115..5 - 12 3 3/3 not connected
116 - 11 13   not connected - no connector
116.5 - 12 2   not connected - no connector
117 - 11 14   not connected - no connector
117.5 - 12 1   not connected - no connector



Notes: The two pink wires on the Q-side are connected to common positive +24V for the blue lights on the upper windchest. The two 1.5mm2 red wires are the common positive voltage for the solenoid valves.
