Logos Robot Orchestra

transportation & insurance data

Go to Godfried-Willem Raes' homepage
Portable robots with netto weight < 32 kg
  • robot description date weight case value (Euro)
    Toypi automated chromatic toy piano (3 octaves) 2008 10kg see note 2
    2.900
    Ob automated oboe 2008 - 2009 17kg 1000x400x460
    13.650
    Korn automated cornet 2008 - 2009 17kg 950x590x390
    8.500
    Casta due 16 castanets 2007 10kg yes
    3.500
    Snar automated snare drum 2006 15kg

    400x430x430

    see note 2

    4.500
    Bono automated valve trombone 2007 - 2008 25kg

    980x360x500

    9.500
    Sire 24 sirens 2005
    yes
    7.500
    Psch 12 small thundersheet noise generators 2006
    yes
    6.000
    Dripper dripping automat, 2002 - 2005 11kg

    420x160x320

    3.800
    Temblo 12 temple blocks 2013 22 kg

    yes
    665x665x720

    11.500
    Whisper cavity resonators 2013 25 kg 700x650x300 case: 900x815x420
    8.500
    HybrHi trebble register organ 2015 21 kg 550 x 260 x 700
    6.000
    Tinti 38 automated tintinabuli with ultrasound 2015 23 kg
    11.000
    Melauton automated soprano melodica 1998 - 2017 5 kg 240 x 480 x 400
    4.000
    Pi buzzer driven pipe organ, serinette (high trebble) 2017 1.7kg 370x70x 306 see note 3
    8.500
    2Pi buzzer driven serinette 2018 1.6 kg 240 x 80 x 290
    3.500
    Flut extended flute 2020 20 kg case: 860 x 500 x 240
    15.500
    Hunt automated hunting horn 2020 15 kg
    5.000
    Trumpeter

    automated trumpet

    [sold to Alain Van Zeveren]

    2021 17 kg

    520 x 660 x 260

    [with stand : h=1500]

    [6.550]
    Cornalto

    automated alto saxhorn

    [sold to Alain Van Zeveren]

    2021 20 kg 920 x 500 x 380
    [9.000]
    Steely robotic steeldrum 2022 8 kg 400 x 400 x 400
    2.800
    3Pi buzzer driven regal 2022 4.5 kg 340 x100 x 440
    4.500
    4Pi membrane driven regal 2022 13 kg

    920 x 110 x 900

    see note 4

    16.000
    Subtotal:
    155.650
  • note: some flightcases are heavier than the robot they hold.
  • 2. <Snar> and <Toypi> share a fightcase, sized 900x500x660
  • 3. <Pi> and <2Pi> fit in a standard aluminium attache case and can even be taken as cabin luggage on airplanes.
  • 4.<4Pi> has a sturdy flightcase, slightly too large for a normal car.

Robots requiring a normal car for transportation

  • robot description date weight case value (Euro)
    Player piano piano vorsetzer #1 1994 45kg yes
    12.500
    PP2 piano vorsetzer #2 2005 45kg yes
    18.000
      now with pedal 2005 30kg -
    4.500
    Bomi automated pipe organ 2010 45kg

    no

    820x330 x1230

    19.000
    Spiro automated spinet 2011 40kg no
    16.500
    Klar automated clarinet 2012 56kg (86kg with case)

    yes (30kg) 425 x 690 x 1235

    robot: 320 x 670 x 1200

    16.500
    Asa automated alto saxophone 2013 40kg 480 x 570 x 926
    14.000
    Horny automated horn 2013 35kg 650 x 650x 700
    12.500
    RoboSnare automated snare drum (made to the order of Aphex Twin) 2014 22kg [53kg with case] 725 x 573 x 580
    6.800
    Chi automated bronze chimes 2016 40kg
    11.500
    Subtotal:
    131.800
  • note: the piano is not included and has always to be provided by the organizer
  • note: Bomi is 1.23 m high and should not be put flat.



Robots requiring a small van for transportation:

  • robot description date weight case value (Euro)
    Harma automated reed organ 2000 - 2005
    half
    16.000
    Autosax automated saxophone 1989 - 2020 40kg -
    14.000
    Xy automated quartertone xylophone 2007
    yes
    13.000
    Ake automated accordion 2004 - 2008
    -
    10.000
    Bako automated bass accordion 2006 - 2008
    -
    9.500
    Tubi automated quartertone tubophone (3 octaves) 2004
    -
    13.500
    Heli automated microtonal helicon 2007 - 2009 53 kg

    -

    1400 x 900 x 590

    12.500
    HarmO automated reed organ 2009 115 kg

    -

    500 x 1165 x 1200

    25.000
    Hat hit anything robot (made for Aphex Twin) 2009 94 kg

    -



    18.500
    Fa automated bassoon 2011 50 kg 1600 x 480x 850
    16.000
    Synchrochord automated bowed monochord 2011 - 2012 60kg none
    12.000
    Rodo automated bronze tines with radar sensors 2013 - 2017 65kg

    none

    size: 1020 x 1100 x 850

    14.500
    Zi automated zither or Qanun 2014-2017
    14.000
    Rumo automated intonarumori 2014-2017
    6.000
    Hybr membrane pipe organ 2014 65kg 1930 x 370 x 1000 (note1)
    17.000
    Balmec
    robotic instruments for Ballet Mecanique
    2014-2015



      <Propeller1> 2015 none
    6.000
      <Propeller2> 2015 none
    6.000
      <Propeller3> 2015 83 kg none
    7.500
      <Bello> 2015 65 kg none
    16.000
      <Balsi> 2019 none
    18.903
    HybrLo subbass membrane driven organ 2016 100 kg

    none

    size: 2140 x 370 x 1100 (note2)

    18.000
    Bug automated flugelhorn 2016-2017 33 kg size: 600 x 700 x 1100 weight with case: 64 kg
    24.000
    Per automated drumkit 2018 36 kg 740 x 350 x 1630
    12.000
    Rumo robotic noise maker 2014-2023
    Subtotal:
    319.903
  • note1: It is allowable to put <Hybr> flat on its backside for transportation.
  • note2: The pipes can be taken off easily and transported flat. The base height then becomes 350 mm.

Robots requiring a truck with elevator for transportation:

  • robot description date weight case value (Euro)
    Belly automated carillon 2001- 2006

    150 kg

    1100x1100x1390

    -
    12.000
    Flex automated singing saws 2001- 2016 135 kg -
    24.000
    Aeio aeolian cello 2007 - 2017 -
    23.500
    Hurdy 2 stringed automated bass hurdy gurdy 2004 - 2007 -
    13.000
    So sousaphone playing robot 2003 - 2020

    60 kg

    2200x700x700

    for horn
    14.500
    Llor twelve large automated stainless steel shell-bells 2005 - 2017 170 kg -
    12.000
    Klung automated brass angklung 1998 - 2015 -
    18.500
    Krum automated pipeorgan, reed pipes 2005 - 2006 -
    22.000
    Simba a cymbal playing robot 2007 -
    8.200
    Puff quartertone puff-organ 2004 - 2007 -
    54.000
    Piperola automated pipeorgan, flue pipes, soprano 1997 - 2006

    120kg

    1680x1400x530

    -
    15.000
    Troms automated drums 2000 - 2004 -
    8.500
    Vacca 48 automated cow bells 2005- 2013 -
    13.500
    Vitello 36 automated cow bells 2006 -
    12.000
    ThunderWood automated 'nature' noises 2000 - 2006 -
    9.500
    Vibi automated vibraphone 2001- 2010 -
    16.000
    Pos positiv organ 2018

    70 kg

    2130 x 1300 x 490

    -
    25.000
    Tubo aluminum celesta 2019

    228 kg

    1935x1272x620

    -
    56.000
    Subtotal:
    357.200

Robots requiring a large and high professional truck with elevator for transportation:

  • robot description date weight case value (Euro)
    Bourdonola automated pipeorgan, wood flue pipes, bass 1997- 2008 -
    14.000
    Qt 6 octave quartertone organ

    2005- 2007

    270 kg -
    74.500
    Vox humanola automated pipeorgan, vox humana 1995 - 2005 240 kg -
    32.600
    Casta uno 15 castanets, integrated in Vox Humanola 1995 - 2005 - -
    included in above
    Trump automated organ trumpet 1999- 2004

    160kg

    400x1100 x 1950

    -
    17.000
    Rotomoton five automated rototoms 2000 - 2007 220 kg -
    19.000
    Springers automated siren, shakers and springs 2000 stands are 6m long
    11.750
    Subtotal:
    168.850


Accessories:

  • item description date weight case value (Euro)
    Invisible Instrument Gesture sensing interface 1993-2016 2 kg yes
    25.000
    PicRadar 8 PIC-radar interfaces 2004 yes
    2.000
    Quadrada Quad 10GHz radar system 2007 yes
    12.000
    Larangus disens Long range ranger 2010 yes
    2.800
    Pyrosens Pyrodetection based interface 2008 yes
    2.200
    8x8 Midi 8-port midi interface 2014 2 kg 19" rack
    1.700
    Laptop PC central server for the orchestra 2018 3 kg yes
    2.200
    Midi wiring 80 cables MIDI yes
    800
    Power wiring 80 mains chords yes
    480
    Saf

    separation transformer for the entire robot orchestra

    2.5kW

    2012 35 kg -
    4.000
    Differential midi drivers 10 midi buffers 2000-2016 4 kg -
    12.000
    Display 1 4-digit midi display A 2014 1 kg
    600
    Display 2 4-digit midi display B 2014 1 kg
    600
    Mirrored x Midi mirroring processor 2016 60 g -
    450
    Kawai piano KG1 baby grand piano 260 kg
    8.000
    Programmers Microchip PIC programmers/debuggers 2002-2020- 2022
    1.100
    Subtotal
    75.930


Endtotal value of the complete robot orchestra: 1.251.833 Euro





A list of robots having a full flightcase:

robot case sizes gross weight position
<Asa> 480 x 570 x 926   upright
<Bono>     flat
<Bug> 610 x 710 x 1100 64 kg upright
<Casta Due>     flat
<Dripper>     upright
<Flut> 860x550x240 20 kg + upright
<Klar> 415 x 690 x 1235 56 kg + 30 kg = 86 kg upright or flat
<Korn>     flat
<Ob>     upright
<Player Piano 1>     flat
<Player Piano 2>     flat
<Psch>     upright
<Sire>     flat
<Snar> (1) 900 x 500 x 660   upright
<Temblo>     upright
<Toypi> (1) 900 x 500 x 660   upright
<Whisper> 900 x 815 x 420   upright
<Xy>     upright
<Pi>

standard attache case

420 x 310 x 125

2.5 kg any
<2Pi>

standard attache case

420 x 310 x 125

2.0 kg any

(1) these robots fit together in one and the same flightcase.



A list of robots also suitable for stand-alone operation:

<Rodo>   radar interfaces
<Aeio> embedded demo file radar interface
<Pos> enbedded demo files
<Bello> embedded demo file
<Simba> embedded demo file
<Klar> embedded demo files
<Pi> embedded demo files
<2Pi> embedded demo files
<Tubo> embedded demo files radar interface
<pp2> palaver piano audio interface
<Steely>   radar interface
<3Pi>   radar interface





Return links:

Remarks:
